OEM206-WP300 12V/24V DC Motor Peristaltic Pump
OEM206/WP300 small peristaltic pump is a compact small liquid supply pump, its small size, compact structure, durable. Three-roller pump head, pulsation is small, without any operator adjustment, reliable performance. Suitable for 1.6mm peristaltic pump hose, its hose models are 13#, 14#, 19#, 16#, 25#, 17#, 18#. Its maximum flow rate is 870L/min. Ideal for fluid transfer application which require high accuracy and repeatability.Pump head is compact and simple in design with same side tubing entry/exit.Perfect for space-limited. OEM206 is a simple liquid transfer pump.Compact structure design, simple installation design, and good working performance, widely used in various liquid processing equipment.The OEM206 pumps have superb features built-in and flexible design to meet specific customer needs.
- It is widely used in laundry rooms, dishwashers, coffee machines, water and fertilizer machines, aquariums, aquaculture systems, hydroponic systems, etc. Typical Application:Washing machine matching,COD water treatment,Detergent Liquid Transferring,Fertigation System, Dosing System, Dish Washer, Washing Machine,BenchtopBioreactors, Wastewater Treatment Analysis Instrument, etc.
Features:
Shell corrosion resistance
New special process plastics are used, which have outstanding stability and corrosion resistance. Corrosion resistance shell.
Visualization pump cover
Visualized pump cover design for easy observation of transmission.
Easy tube change
Tube fitting design, easy to change tubes
High performance in fluid transfer
Maximum flow rate up to 870ml/min.
| Model | OEM206 |
| Pump Head | WP300 |
| Motor | 12/ 24 DC Deceleration motor |
| Channels | 1 |
| Rollers | 3 |
| Max Speed(rpm) | 300 |
| Max Flow (mL/min) | 870mL/min |
| Tube Specifications | 13#,14#,19#16#,25#,17# |
| Roller Material | PP |
- Certification:
- CE
- Structure:
- Peristaltic Pump
- Model Number:
- OEM206
- Speed:
- 300rpm
- Max Flow rate:
- 870ml/min
